Kauo Heng Precision Machinery Co., LTD. established in 1972, is an up and coming company focused on manufacturing high quality and efficient computerized flat-knitting machines. In line with the consistent sincere letter and steady and sure management idea, Kauo Heng Company improves the professional technique and R&D constantly.
Flat Knitting Machines KH-300HP
Feature
COMPUTERIZED CONTROL
Computer control with LCD display, data direct input easy to key in programs, easy to operate, read and obtain information as to the performance of machine. LCD displays the number of pieces to be knitted and how many were already knitted. All the information is very clearly displayed on LCD panel.
YARN FEEDER
Feeders made of special steel which prevents them from shaking during knitting.This eliminates yarn breakage. They are also easy to thread the yarn through.
SPECIFICATIONS KAUO HENG KH-300 |
||
|
GAUGE |
3G, 3.5G, 4G | 5G, 7G, 10G, 12G, 14G, 16G |
|
KNITTING WIDTH |
46″ (117cm), 80″ (203cm) | 50″ (127cm) , 80″ (203cm), 100″ (254cm) |
|
CAM SYSTEM |
Single System, Twin Carriage.
|
50″ : Double System 80″ : Single System, Twin Carriage. 100″ : Single System, Twin Carriage. |
| Knitting System Three-Way Technique And Transfer With Split Stitch Function. | ||
|
KNITTING SPEED |
Max. 1.2 M/Sec. Knitting Speed Varies According To Gauge, Yarn And Knitting Conditions. |
|
|
YARN CARRIERS |
12 Yarn Carriers On 3 Double Rails | 12 Yarn Carriers On 3 Rails 16 Yarn Carriers On 4 Rails |
|
NEEDLE SELECTION |
Full Jacquard Selection Via Special Solenoids. | |
|
TRANSFER |
Simultaneous Transfer, Front Or Back, Independent Of Carriage Direction
Split Knitting. |
|
|
NEEDLE BED |
Replaceable Segment Needle Bed. | |
|
SINKER SYSTEM |
Moveable Sinker Equipment. | |
|
STITCH DENSITY |
30 Levels Independent Selection, Electronic Control With Stepping Motor 00-200 Steps. | |
|
RACKING |
Racked By Servo Motor And High Precision Ball Screw System. Racking Also Available 1/2 Pitch From Any Position. |
|
|
FABRIC TAKE DOWN |
Main Roller / Sub Roller :
32 Levels Changeable Speed, Automatically Adjustable On Each Level. |
|
|
STOP MOTION |
Yarn Break, Knot, Press Off, Needle Break, Shock, Over Torque, Piece Count, Over Run, Program Error Etc | |
|
DRIVE |
AC Servo Motor, Tooth Shape Driving Belt, No Oil Needed. Variable Adjustable Programmable Speed Levels. |
|
|
TOP TENTIONS |
Electronic Top Tensions Easy To Thread The Yarn Through. | |
|
YARN FEED UNIT |
Auto. Positive Feeding Device On Each Left And Right Side. | |
|
SAFETY COVER |
Full Safety Cover For Anti-Noise And Dust Proofing.
Emergency Stop Buttons. |
|
|
OPERATION LAMP |
Green : Normal Operation. Yellow : Abnormal Stop. |
|
|
FLUORESCENT LAMP |
Inside Of Safety Cover And Fabric Take Down. | |
CONTROLLER |
||
|
DATA INPUT |
3.5″ Micro Floppy. | |
|
OPERATION & DISPLAY |
LCD Display Screen, Chinese And English Versions Available. | |
|
PATTERN MEMORY |
1,024 Wales X 4,096 Courses. | |
|
POWER |
3 Phase AC 220V 50/60HZ | |
